SPP31192-02T

  10G SFP+ Optical Transceiver, 2km Reach LC

Features

• Multi-Rate support from 1Gbps to 10.1Gbps
   Up to 2kmTransmission on SMF

  1310nm PIN photo-detector

  SFP+ (Small Form-factor Pluggable Plus) SFF-8431 Compliant
  SFP+ Package with Single LC Connector, Bi-directional
   Digital Diagnostic SFF-8472 Compliant
   Single 3.3V Power Supply
   Low Power Consumption
  Hot Pluggable
   Operating Case Temperature:
  -5 to 70 °C
  -40 to 85 °C
   All-metal Housing for Superior EMI Performance
   Telcordia GR-468 Compliant

Applications

l  10GBASE-BX at 10.3125/9.953Gbps

l  10GBASE-LR/W at 10.3125/9.953Gbps

l  1G,2G,4G,8G Fiber Channel

Product Description

SPP31192-02T SFP+ transceiver designed to transmit and receive optical data over 2km single mode optical fiber(SMF) with a BOSA including 1310nm PIN receiver. The transceiver comply with SFP+ (Small Form-factor Pluggable Plus) SFF-8431 MSA, and can support Multi-rate from 1Gbps to 11Gbps for 10G Ethernet LAN(10.325Gb/s) and WAN(9.95Gb/s) application. Digital diagnostics functions are available via I2C which is Compliant with SFF-8472.

Ordering Information
